Oxford Major 200 Hoist

Product Code: MH0045

Item for sale to registered trade customers only.

Trade customers please log in to see buying options or contact us to open an account.

Oxford Major 200 Hoist

The Oxford Major is the perfect cross over product for both nursing and acute care environments. It’s high lift capacity and relative lightweight design ensures the Major has a place in almost all care environments.

Specifications
Downloads

Safe Working Load: 200kg / 31st / 441Ibs

Length: 1300 mm

Maximum Overall Height: 1930 mm

Minimum Overall Height: 1380 mm

Maximum Spreader Bar Height: 1715 mm

Minimum Spreader Bar Height: 565 mm

Spreader Bar Height at Maximum Reach: 1200 mm

Spreader Bar Reach at Maximum Height: 610 mm

Spreader Bar Reach at Minimum Height: 515 mm

Maximum Reach 720 mm:

Turning Radius 1310 mm:

Legs Open – External Width: 1230 mm

Legs Open – Internal Width: 1140 mm

Legs Closed – External Width: 660 mm

Legs Closed – Internal Width: 580 mm

Overall Height of Legs: 100 mm

Ground Clearance: 15 mm

Front Twin Castors: 75 mm

Rear Braked Castors: 100 mm
